1U K-126L Item No.: 88887000

The 1U K-126L is the perfect rack for a small and cost-effective server system.

Its compact design and its small installation depth of 250mm for ITX boards allows this case to fit into nearly every rack.

The 1U K-126L provides internal space for optional 1x 3.5" or 2x 2.5" hard disks. Two serial 40mm fans, which are internally mounted behind the front panel, ensure a reliable and optimal cooling.

Further you can two USB 2.0 connectors in the front of the case next to the controls.

Suitable cables can be found here: Cable program

Motherboard
Form factor	Mini ITX
Installation Dimensions
Height CPU cooler (max.)	32mm
Length graphics card (max.)	170mm
Drive Bays
5.25" external
5.25" external (slim)
3.5" external
3.5" internal	1x¹
2.5" internal	2x¹
Front connectors
USB 3.0
USB 2.0	2x
Power supply
FlexATX PSU
Fan mounting option
Inside	2x 40mm (serial, Molex connector)
Controls & LED
Controls	Power-Switch Reset-Button
LED	Power HDD Activity
other Data
Dimensions (h/w/d)	45 x 485 x 285mm
Material	1.0-1.2mm Steel
Warranty	24 months
Scope of delivery & Features
Scope of delivery	Case Retail packaging Screw Set Brackets for optional FlexATX PSU I/O Shield (Universal for cut out)
Features	Only 250mm Depth Serial 2x 40mm fan USB 2.0 intern as block connector
Logistical data
Shipping Unit	1 Pcs
EU palett	45 Pcs
Weight	net = 2.59kgs gross = 3.62kgs
Item number	88887000
EAN-Code	4260133129849

¹ can vary by using several mounting options

No further information is available for this product.
